Structural Windows
The Structural window is a development of our Pollux window, a glulam window that allows all possibilities and combinations. A Structural Glazing glass covers the entire leaf or frame. This allows a flush finish to the facade. The Structural window allows for a refined design that is highly sought-after in contemporary architecture. It requires no maintenance and offers easy cleaning, as there are no edges to retain dirt. The external enameled strip can be chosen in the RAL shade of your choice and thus matches your facade. The Structural window is available in several combinations, whether by italian sash windows, sliding, as a front door or as a facade element.
Our gluing is carried out with a 2-component silicone, certified EOTA ETAG 002 and ASTM C 1184 (European standards).
The outer glass of a Structural window is tempered glass, with high resistance to frontal impacts.
References
Beaumont
Chetzeron Hotel
Crans-Montana
IDHEAP
Renens
Louise Bron Home
Fully
Petit Lac
Sierre
Municipal Police
Sierre
Borzuat School
Sierre
Villa
Sion 1
Villa
Sion
Performance
| Frame Insulation Coefficient | Uf 1.455 - 1.533 W/m²k | |
| Glass Insulation Coefficient | Ug 0.5 - 0.7 W/m²k | |
| Overall window insulation coefficient | Uw jusqu'à 0.84 W/m²k | |
| Energy saving | g 58 - 62 % | |
| Acoustic glazing insulation | Rw tested at 47 dB | |
| Thickness of glass on sashes | until 54 mm |
Cuts
